Custom Size B270 Optical Filter
Explore our 808nm notch filter with 85% transmittance and OD2-OD6 blocking density, ideal for fluorescence and laser applications.
Core attributes
- Material
- B270
- Size
- Custom
- Thickness
- 0.3 mm
- Surface Quality
- 40/20
- Transmittance
- 85%
- Filter Type
- notch
- Cwl
- 808nm
- Coating
- iad-pvd
- Transmission bands
- NIR (0.7-1.7 μm)
Product facts
Key attributes
- Material
- B270
- Size
- Custom
- Thickness
- 0.3 mm
- Surface Quality
- 40/20
- Transmittance
- 85%
- Filter Type
- notch
- Cwl
- 808nm
- Coating
- iad-pvd
- Transmission bands
- NIR (0.7-1.7 μm)
Product description
The 808nm notch filter is designed to effectively block unwanted wavelengths while allowing specific light to pass through, making it ideal for applications in fluorescence microscopy and laser systems. With a transmittance of 85% and a blocking density of OD2-OD6, this filter ensures excellent performance in demanding environments. Constructed from B270 glass and featuring iad-pvd coatings, it offers durability and reliability for various optical applications.
Key Features
- Transmittance of 85% ensures high light throughput for optimal imaging.
- Blocking density of OD2-OD6 provides effective rejection of unwanted wavelengths.
- Available thicknesses between 0.3mm and 5.0mm for versatile integration.
- Manufactured with double-sided polishing for superior surface quality (40/20).
- Customizable options available including OEM and ODM support.
Specification Summary
| Item | Value |
|---|---|
| Material | B270 |
| Size | Custom |
| Thickness | 0.3 mm |
| Surface Quality | 40/20 |
| Transmittance | 85% |
| Filter Type | notch |
| Cwl | 808nm |
| Coating | iad-pvd |
| Transmission bands | NIR (0.7-1.7 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 85%; >85% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Coating Region | Single-sided or double-sided |
| Manufacture | Double sided polishing |
| Materials | B270,JGS1,Quartz Glass,Absorptive Glass |
| Blocking Density | OD2-OD6 |
| Tolerance | ± 0.10mm |
| Shipment | Express delivery,Air,Sea |
FAQ
Can I get custom sizes for this filter?
Yes, customizable options are available including OEM and ODM support.
What is the tolerance for this filter?
The tolerance for this filter is ± 0.10mm.
