1 / 6Optical Filters
Custom Size B270 Optical Filter
High-performance 520 nm bandpass filter with 90% transmittance, ideal for laser applications. Custom sizes available.
Core attributes
- Material
- B270
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- bandpass
- Cwl
- 520nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product facts
Key attributes
- Material
- B270
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- bandpass
- Cwl
- 520nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product description
This bandpass filter is designed for laser applications, providing optimal performance with a center wavelength of 520 nm and a high transmittance of 90%. Its iad-pvd coating enhances durability, making it suitable for various environments. The filter’s design ensures effective light management, essential for precision in fluorescence microscopy and other optical systems. Custom sizing options are available to meet specific project requirements.
Key Features
- High transmittance of 90% for efficient light passage.
- Center wavelength of 520 nm, ideal for laser applications.
- Durable iad-pvd coating for enhanced environmental resistance.
- Customizable dimensions and angles of incidence for tailored solutions.
- Express delivery options ensure timely project support.
Applications
Laser
Specification Summary
| Item | Value |
|---|---|
| Material | B270 |
| Size | Custom |
| Thickness | Custom |
| Transmittance | 90% |
| Filter Type | bandpass |
| Cwl | 520nm |
| Coating | iad-pvd |
| Transmission bands | VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 90% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Transmission | High |
| Slope | Steeper |
| Tolerance | ±0.2 mm |
| Aoi | Can be customized |
| Customized | Yes |
| Shipment | Express delivery,Air,Sea |
FAQ
Can I get custom sizes?
Yes, custom sizes and angles of incidence can be accommodated.
What is the minimum order quantity?
There is no specified minimum order quantity.
