1 / 6Optical Filters
5 mm B270 Round Optical Filter
Discover the 808nm IR Long Pass Filter with 85% transmittance and OD>3 blocking for optimal infrared applications.
Core attributes
- Material
- B270
- Shape
- Round
- Size
- 5 mm
- Thickness
- Custom
- Transmittance
- 85%
- Filter Type
- longpass
- Cwl
- 808nm
- Coating
- hard-coat
- Transmission bands
- NIR (0.7-1.7 μm)
Product facts
Key attributes
- Material
- B270
- Shape
- Round
- Size
- 5 mm
- Thickness
- Custom
- Transmittance
- 85%
- Filter Type
- longpass
- Cwl
- 808nm
- Coating
- hard-coat
- Transmission bands
- NIR (0.7-1.7 μm)
Product description
The 808nm IR Long Pass Filter is designed to effectively transmit infrared light while blocking unwanted wavelengths, making it ideal for applications in fluorescence microscopy and thermal imaging. With a high transmittance of 85% and a blocking depth of OD>3 across the 400-1200nm range, this filter ensures optimal performance in demanding environments. Its hard-coated surface provides enhanced durability, ensuring reliable operation over time.
Key Features
- Transmittance of 85% for efficient light transmission.
- Longpass filter type specifically designed for 808nm applications.
- OD>3 blocking depth from 400-1200nm for superior wavelength rejection.
- Hard-coated for enhanced environmental durability.
- Customizable options available for OEM, ODM, and OBM needs.
Specification Summary
| Item | Value |
|---|---|
| Material | B270 |
| Shape | Round |
| Size | 5 mm |
| Thickness | Custom |
| Transmittance | 85% |
| Filter Type | longpass |
| Cwl | 808nm |
| Coating | hard-coat |
| Transmission bands | NIR (0.7-1.7 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 85% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Filter Type | 808nm IR Long Pass Filter |
| Coating Type | Hard Coated |
| Scratch-Dig | 40/20,60/40,80/50 |
| Center Wavelength | 808nm |
| Peak Transmission(Tp) | >85% |
| Blocking Band | OD>3,400-1200nm |
| Certification | RoHs,ISO9001,EPR |
FAQ
Can I get custom sizes?
Yes, customizable options are available for OEM, ODM, and OBM requirements.
What is the minimum order quantity (MOQ)?
The minimum order quantity (MOQ) is not specified.
