10 mm BK7 Beamsplitter, AR Coated
BK7 beamsplitter with 95% transmittance, customizable sizes, and broad wavelength compatibility from 0.4 to 1.7 μm.
Core attributes
- Material
- BK7
- Size
- 10 mm
- Thickness
- Custom
- Surface Quality
- 20/10
- Transmittance
- 95%
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- BK7
- Size
- 10 mm
- Thickness
- Custom
- Surface Quality
- 20/10
- Transmittance
- 95%
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
This BK7 beamsplitter is designed to effectively manage light across a wide range of wavelengths from 0.4 to 1.7 μm, making it ideal for applications in laser systems, machine vision, and biomedical imaging. With a high transmittance of 95%, it ensures minimal loss of light while maintaining excellent surface quality (20/10). Its versatility supports various optical setups, allowing for reliable performance in demanding environments.
Key Features
- High transmittance of 95% for efficient light management.
- Compatible with wavelengths from 0.4 to 1.7 μm for broad application use.
- Surface quality rated at 20/10 for superior optical clarity.
- Customizable options available for OEM and ODM projects.
- Available sizes ranging from 10 mm to 200 mm to fit specific requirements.
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Size | 10 mm |
| Thickness | Custom |
| Surface Quality | 20/10 |
| Transmittance | 95% |
| Coating | anti-reflective (AR) |
| Transmission bands | NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 95%; 98%; 80-90%/customize |
| Customized Support | OEM, ODM |
| Warranty | 3 Years |
| Wavelength | 200-1100nm |
FAQ
Can I get custom sizes for the beamsplitter?
Yes, sizes can be customized between 10 mm and 200 mm.
What is the minimum order quantity (MOQ)?
The MOQ is not specified, allowing for flexible ordering.
