25.4 mm BK7 Corner-cube Optical Prism
Explore our Corner Cube Prism for surveying with high accuracy and customization options.
Core attributes
- Material
- BK7
- Shape
- Corner-cube
- Size
- 25.4 mm
- Thickness
- Custom
- Surface Quality
- 1/4
Product facts
Key attributes
- Material
- BK7
- Shape
- Corner-cube
- Size
- 25.4 mm
- Thickness
- Custom
- Surface Quality
- 1/4
Product description
The Corner Cube Prism is designed for precise surveying applications, providing accurate retroreflection of light. With a prism constant of 17.5mm and an accuracy of less than 5 arc seconds, it ensures reliable measurements in various environmental conditions. Made from BK7 glass, this prism is suitable for a range of optical paths and can be customized to meet specific project requirements.
Key Features
- Corner cube geometry ensures accurate retroreflection for surveying applications.
- Surface quality of 1/4 supports high wavefront integrity.
- Effective diameter of 25.4mm fits standard surveying equipment.
- Customized support available for ODM and OEM projects.
- Threaded package sizes (5/8’’-11, 3/8’’-16, M8) for versatile mounting options.
Applications
Surveying
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Corner-cube |
| Size | 25.4 mm |
| Thickness | Custom |
| Surface Quality | 1/4 |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Surveyor’S Prisms, Corner Cube |
| Customized Support | ODM, OEM |
| Warranty | 1 Year |
| Effective Diameter | 25.4mm |
| Prism Constant | 17.5mm |
| Accuracy | <5" |
| Single Package Size | Thread 5/8’’-11; Thread 3/8’’-16; Thread M8 |
FAQ
Can I get custom sizes?
Yes, customized support is available for ODM and OEM projects.
What is the accuracy of the prism?
The prism offers an accuracy of less than 5 arc seconds.
