1 / 6Beamsplitters
1 mm BK7 Cube Beamsplitter
BK7 beam splitter prism with 90% clear aperture, 40/20 surface quality, and customizable sizes for optical applications.
Core attributes
- Material
- BK7
- Shape
- Cube
- Size
- 1 mm
- Thickness
- Custom
- Surface Quality
- 40/20
Product facts
Key attributes
- Material
- BK7
- Shape
- Cube
- Size
- 1 mm
- Thickness
- Custom
- Surface Quality
- 40/20
Product description
This BK7 beam splitter prism is designed to meet the precise needs of various optical applications, ensuring high performance with a clear aperture of 90%. Ideal for laser, machine vision, and microscopy applications, it provides reliable beam splitting capabilities. With a surface quality of 40/20 and a surface flatness of 1/4 lambda, it is suitable for demanding optical setups. Sourced from Henan, this prism supports custom sizes and configurations to fit specific project requirements.
Key Features
- High surface quality of 40/20 for optimal optical performance.
- Clear aperture of 90% ensures minimal light loss.
- Surface flatness of 1/4 lambda for precise beam splitting.
- Customizable options available for OEM, ODM, and OBM.
- Available in sizes ranging from 1.0 mm to 100.0 mm.
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Cube |
| Size | 1 mm |
| Thickness | Custom |
| Surface Quality | 40/20 |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | beam spliter prism |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Materail | BK7 Glass/quartz Glass |
| Clear Aperture | 90% |
| Color | Transparent |
| Surface Flatness | 1/4lambda |
FAQ
Can I get custom sizes for this beam splitter?
Yes, this beam splitter prism supports custom sizes and configurations.
What is the minimum order quantity (MOQ)?
The minimum order quantity is not specified, allowing for flexible procurement.
