Custom Size BK7 Dove Optical Prism, AR Coated
Explore high-precision dove prisms with 40/20 surface quality and 3 arcminute angle tolerance for optical applications.
Core attributes
- Material
- BK7
- Shape
- Dove
- Size
- Custom
- Thickness
- Custom
- Surface Quality
- 40/20
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- BK7
- Shape
- Dove
- Size
- Custom
- Thickness
- Custom
- Surface Quality
- 40/20
- Coating
- anti-reflective (AR)
Product description
Dove prisms are essential for applications requiring image inversion and rotation without altering the image size. These prisms are ideal for integrating into optical systems in laser, LIDAR, and machine-vision applications. With a surface quality of 40/20 and an angle tolerance of 3 arcminutes, they ensure high precision and reliability in optical paths.
Key Features
- Surface quality of 40/20 ensures minimal wavefront distortion for high fidelity imaging.
- Angle tolerance of 3 arcminutes provides reliable alignment in precision applications.
- Clear transparent BK7 material offers excellent optical clarity for various wavelengths.
- Customizable options available through OEM, ODM, and OBM support for tailored solutions.
- Clear aperture ranging from 80% to 95% maximizes light transmission efficiency.
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Dove |
| Size | Custom |
| Thickness | Custom |
| Surface Quality | 40/20 |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Right Angle Prism, Corner Cube, Penta Prism, Surveyor’S Prisms, Triangular Prism… |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Color | Clear Transparent |
| Clear Aperture | 80%~95% |
| Angle Tolerance | 3 Arcmin |
| Dimension Tolerance | 0.1mm |
FAQ
Can I get custom sizes for the dove prism?
Custom sizes are supported through OEM, ODM, and OBM options.
What is the angle tolerance for this prism?
The angle tolerance for the dove prism is 3 arcminutes.
