30 mm BK7 Equilateral Optical Prism
BK7 equilateral prism for spectroscopy with 90% clear aperture and high surface flatness. Custom sizes available.
Core attributes
- Material
- BK7
- Shape
- Equilateral
- Size
- 30 mm
- Thickness
- Custom
- Coating
- uncoated
Product facts
Key attributes
- Material
- BK7
- Shape
- Equilateral
- Size
- 30 mm
- Thickness
- Custom
- Coating
- uncoated
Product description
The BK7 equilateral prism is designed for precision optical measurements in spectroscopy applications. Its right-angle geometry ensures optimal beam deviation and accurate light manipulation. With a clear aperture of 90% and a surface flatness of 1/4@633nm, this prism provides reliable performance for laboratory and field use. The uncoated surface allows for versatile integration into various optical setups.
Key Features
- Right-angle geometry for effective beam deviation in spectroscopy applications.
- Surface flatness of 1/4@633nm ensures high wavefront integrity.
- Clear aperture of 90% maximizes light throughput.
- Thickness tolerance of 0.01~0.05mm for precise fitting in optical paths.
- Customized support available for OEM and ODM projects.
Applications
Spectroscopy
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Equilateral |
| Size | 30 mm |
| Thickness | Custom |
| Coating | uncoated |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Right Angle Prism |
| Customized Support | OEM, ODM |
| Warranty | 3 months |
| Flatness | 60/40 |
| Surface Flatness | 1/4@633nm |
| Clear Aperture | 90% |
| Thickness Tolerance | 0.01~0.05 |
| Diameter Tolerance | +0/-0.05mm |
| Use | Optical Measurements |
FAQ
Can I get custom sizes for this prism?
Customized support is available for OEM and ODM projects.
What is the thickness tolerance of the prism?
The thickness tolerance is 0.01~0.05mm.
