1 / 6Optical Prisms
Custom Size BK7 Equilateral Optical Prism, AR Coated
Equilateral BK7 prism with AR coating for machine vision and research. High precision with customizable options available.
Core attributes
- Material
- BK7
- Shape
- Equilateral
- Size
- Custom
- Thickness
- Custom
- Surface Quality
- 60/40
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- BK7
- Shape
- Equilateral
- Size
- Custom
- Thickness
- Custom
- Surface Quality
- 60/40
- Coating
- anti-reflective (AR)
Product description
The equilateral prism made from BK7 optical glass is designed for applications in machine vision and research. Its precise geometry and AR coating enhance light transmission while minimizing glare, making it ideal for high-accuracy optical paths. With a dimension tolerance of +0/-0.2mm and an angle tolerance of less than 3 arc minutes, this prism ensures consistent performance in demanding environments.
Key Features
- Surface quality of 60/40 ensures minimal distortion for accurate measurements.
- Angle tolerance of <3 arc minutes guarantees precision in optical alignment.
- AR coating enhances light transmission and reduces glare for improved visibility.
- Clear aperture >90% maximizes light throughput for efficient performance.
- Customizable support including OBM, ODM, and OEM options available.
Applications
Machine Vision, Research
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Equilateral |
| Size | Custom |
| Thickness | Custom |
| Surface Quality | 60/40 |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Triangular Prism |
| Customized Support | OBM, ODM, OEM |
| Dimension Tolerance | +0/-0.2mm |
| Thickness Tolerance | ±0.2mm |
| Flatness | 1/4 Lambda |
| Clear Aperture | >90% |
| Angle Tolerance | <3 arc minute |
| Chamfer | <0.2-0.5mm*45° |
FAQ
What are the tolerances for dimensions?
The dimension tolerance is +0/-0.2mm and thickness tolerance is ±0.2mm.
Can I get custom sizes for this prism?
Custom sizes are supported through OBM, ODM, and OEM options.
