Custom Size BK7 Plate Beamsplitter
BK7 plate beamsplitter for 400-700 nm and 0.7-1.7 μm applications, customizable with high transmittance.
Core attributes
- Material
- BK7
- Shape
- Plate
- Size
- Custom
- Thickness
- 0.3 mm
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm)
Product facts
Key attributes
- Material
- BK7
- Shape
- Plate
- Size
- Custom
- Thickness
- 0.3 mm
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm)
Product description
This BK7 plate beamsplitter is designed for applications across a wide range of wavelengths, specifically from 400-700 nm and 0.7-1.7 μm. It effectively divides light into two paths, making it ideal for laser, machine vision, and microscopy applications. The beamsplitter’s high transmittance ensures optimal performance, while its customizable options allow for tailored solutions to fit specific project needs.
Key Features
- Transmittance of 50% for effective light division, enhancing system performance.
- Customizable support for OEM, ODM, and OBM, allowing tailored solutions.
- Compatible substrates include BK7, K9, B270, D263T, and fused silica for versatile applications.
- Thickness options range from 0.3 mm to 5.0 mm, accommodating various system requirements.
- Clear aperture covers greater than 95% of the active area, maximizing light utilization.
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Plate |
| Size | Custom |
| Thickness | 0.3 mm |
| Transmission bands | NIR (0.7-1.7 μm), VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | Fifty Percent; R/T |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 years |
| Substrate | K9,BK7,B270,D263T, fused silica |
| Clear Aperture | Coating cover greater 95% active area |
FAQ
What are the available thickness options?
Thickness options for this beamsplitter range from 0.3 mm to 5.0 mm.
Can I get custom sizes?
Yes, the beamsplitter supports OEM, ODM, and OBM for customized solutions.
