1 / 6Optical Mirrors
10 mm BK7 Rectangle Optical Mirror
Explore high-performance BK7 laser scanning mirrors with 99.5% reflectance for precision applications.
Core attributes
- Material
- BK7
- Shape
- Rectangle
- Size
- 10 mm
- Thickness
- Custom
- Reflectance
- 99.5%
- Transmittance
- 95%
- Coating
- protected gold, dielectric HR
- Transmission bands
- LWIR (8-14 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- BK7
- Shape
- Rectangle
- Size
- 10 mm
- Thickness
- Custom
- Reflectance
- 99.5%
- Transmittance
- 95%
- Coating
- protected gold, dielectric HR
- Transmission bands
- LWIR (8-14 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
The BK7 Laser Scanning System Mirror is designed for high-performance applications in laser systems, offering exceptional reflectance across multiple wavelength bands including UV and IR. With a reflectance of 99.5% and transmittance of 95%, this mirror is ideal for laser marking, engraving, and welding. Its protected gold and dielectric high-reflectance coatings ensure durability and efficiency, making it a reliable choice for precision optical systems.
Key Features
- Reflectance of 99.5% ensures minimal light loss, enhancing system efficiency.
- Coatings include protected gold and dielectric HR for durability and high performance.
- Compatible with multiple wavelengths (355nm, 532nm, 1064nm, 10600nm) for versatile applications.
- Custom sizes available to meet specific project requirements.
- Lightweight design at 0.5 kg facilitates easy integration into existing systems.
Applications
Laser
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Rectangle |
| Size | 10 mm |
| Thickness | Custom |
| Reflectance | 99.5% |
| Transmittance | 95% |
| Coating | protected gold, dielectric HR |
| Transmission bands | LWIR (8-14 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Laser Scanning System Mirror, UV Scanning Vibrating Lens (Galvo Mirror), YAG / F… |
| Customized Support | OBM, ODM, OEM |
| Warranty | 1 Year |
| Weight | 0.5kg(1.10lb) |
| Wavelength | 355nm / 532nm / 1064nm / 10600nm |
| Transmittance | T≥95% @532nm |
| Reflectivity | ≥99.5% @ Design Wavelength |
FAQ
Are custom sizes available?
Yes, custom sizes can be provided to meet specific application needs.
What is the minimum order quantity?
The minimum order quantity is not specified, allowing flexibility for procurement.
