0.5 mm BK7 Right-angle Optical Prism
Explore our right-angle prism for laser, projection, and surveying applications with customizable sizes and high precision.
Core attributes
- Material
- BK7
- Shape
- Right-angle
- Size
- 0.5 mm
- Thickness
- Custom
- Coating
- dielectric HR, uncoated
- Transmission bands
- VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- BK7
- Shape
- Right-angle
- Size
- 0.5 mm
- Thickness
- Custom
- Coating
- dielectric HR, uncoated
- Transmission bands
- VIS (400-700 nm), UV (<400 nm)
Product description
The right-angle prism offers precise optical path control for applications in laser systems, projection, and surveying. With high-efficiency total internal reflection, it ensures minimal loss and exceptional stability. Designed for wavelengths from 400-700 nm and below 400 nm, this prism supports various coatings, including dielectric high-reflective options. Its customizable dimensions range from 0.5 mm to 300 mm, making it suitable for diverse applications while maintaining high accuracy and reliability.
Key Features
- Angle accuracy of ≤3 arc min ensures precise optical alignment.
- Custom sizes from 0.5 mm to 300 mm accommodate various system requirements.
- High clear aperture of 98% maximizes light transmission.
- Compatible with dielectric high-reflective coatings for enhanced performance.
- Flatness of 1/4 Lambda maintains wavefront integrity.
Applications
Laser, Projection, Surveying
Specification Summary
| Item | Value |
|---|---|
| Material | BK7 |
| Shape | Right-angle |
| Size | 0.5 mm |
| Thickness | Custom |
| Coating | dielectric HR, uncoated |
| Transmission bands | VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Right Angle Prism |
| Customized Support | OEM |
| Warranty | None |
| Color | Clear Transparent |
| Brand | JLGD |
| Flatness | 1/4 Lambda |
| Clear Aperture | 98% |
| Materail | BK7 K9L Quartz Glass |
FAQ
Can I get custom sizes?
Yes, the prism can be customized in sizes ranging from 0.5 mm to 300 mm.
What are the angle tolerances?
The angle accuracy is ≤3 arc min, with parallelism less than 1 arc sec.
Product inquiry
Request a quote
Share your application and target specifications. Optional optical details help clarify the request.
