1 mm Borosilicate Round Optical Window, AR Coated

Product description

This round convex lens made from borosilicate glass is ideal for applications in the medical field, particularly in the 8-14 μm and 3-5 μm wavelength bands. Its anti-reflection coating enhances performance by minimizing reflections, making it suitable for sensitive optical systems. With a diameter range from 1.0 mm to 400.0 mm, this lens can be tailored to fit various applications, ensuring optimal compatibility and functionality.

Key Features

Diameter range: 1.0 mm to 400.0 mm for versatile application fit.
Surface quality of 60/40 for reliable optical performance.
Parallelism of 2 arc seconds ensures precise alignment.
Clear aperture greater than 92% for maximum light transmission.
Custom lengths available to meet specific project requirements.

Applications

Medical

Specification Summary

Item	Value
Material	Borosilicate
Shape	Round
Diameter	1 mm
Thickness	Custom
Surface Quality	60/40
Coating	anti-reflective (AR)
Transmission bands	LWIR (8-14 μm), MWIR (3-5 μm)
MOQ	—

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM
Warranty	3 months
Weight	0.01
Parallelism	2 arc seconds
Centering	30 arc min
Irregularity	L/4
Clear Aperture	>92%
Length	custom

FAQ

Can I get custom sizes for the lenses?

Yes, custom diameters and lengths are available to meet specific application needs.

What is the minimum order quantity (MOQ)?

The MOQ is not specified, allowing for flexible ordering based on project requirements.
