1 mm Borosilicate Round Optical Window, AR Coated

Product description

This round borosilicate window is designed for medical applications, offering optimal performance within the 0.7-1.7 μm wavelength range. Its anti-reflective coating reduces glare, enhancing image clarity. The window’s lightweight and durable design ensures long-term use, while customizable dimensions allow for tailored solutions to meet specific project requirements.

Key Features

Wavelength range: 0.7-1.7 μm for versatile medical applications.
Anti-reflective coating minimizes glare, improving image clarity.
Surface quality of 40/20 ensures high optical performance.
Lightweight design at only 0.03 grams for easy handling.
Custom sizes available to fit specific project needs.

Applications

Medical

Specification Summary

Item	Value
Material	Borosilicate
Shape	Round
Diameter	1 mm
Thickness	Custom
Surface Quality	40/20
Coating	anti-reflective (AR)
Transmission bands	NIR (0.7-1.7 μm)
MOQ	—

Full Specifications

Parameter	Value
Type	WINDOW; Window
Customized Support	OEM
Warranty	3 Months
Weight	1
Parallelism	2 arc seconds
Clear Aperture	>=central 80% of diameter
Surface Flatness	1/4@633nm
Centering	30 arc min

FAQ

Can I get custom sizes for this window?

Yes, customizable dimensions are available to accommodate various project needs.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing for flexible sourcing.
