2 mm Borosilicate Round Optical Window, AR Coated

Product description

This borosilicate round window is specifically designed for medical applications within the 400-700 nm wavelength range. Its robust construction and high-performance specifications, including a surface quality of 60/40 and a clear aperture greater than 92%, ensure optimal light transmission and durability. Ideal for demanding environments, this window is customizable and can be tailored to meet specific project requirements.

Key Features

Diameter range: 2.0 mm to 200.0 mm for versatile application fit.
Surface quality of 60/40 ensures reliable performance in optical systems.
High clear aperture (>92%) maximizes light transmission efficiency.
Parallelism of 2 arc seconds for precise optical alignment.
Custom lengths available from 10 mm to 500 mm to suit specific needs.

Applications

Medical

Specification Summary

Item	Value
Material	Borosilicate
Shape	Round
Diameter	2 mm
Thickness	Custom
Surface Quality	60/40
Coating	anti-reflective (AR)
Transmission bands	VIS (400-700 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	FLAT
Customized Support	OEM
Warranty	3 months
Weight	0.01KG(0.02lb)
Parallelism	2 arc seconds
Centering	30 arc min
Irregularity	L/4
Clear Aperture	>92%
Length	custom

FAQ

What custom sizes are available?

Custom lengths can be provided from 10 mm to 500 mm, and diameters range from 2.0 mm to 200.0 mm.

What are the tolerances for this window?

The tolerances for this window are +/-0.1 mm.
