3x0.1 mm Borosilicate Round Optical Window, AR Coated

Product description

Borosilicate optical windows are ideal for security applications, offering exceptional durability and optical clarity. With a diameter range from 3.0 mm to 460.0 mm and a consistent thickness of 0.15 mm, these windows meet various design requirements. The surface quality rating of 10/5 ensures minimal distortion, making them suitable for precision optical systems. Customization options are available to fit specific project needs.

Key Features

Diameter range: 3.0 mm to 460.0 mm for versatile applications.
Thickness of 0.15 mm ensures uniformity and compatibility with various systems.
Surface quality of 10/5 provides high clarity and minimal distortion.
Diameter tolerance of +/-0.01 mm for precise fitting.
OEM and ODM support available for customized solutions.

Available Sizes

Diameter x Thickness (mm)
231.5 x 0.1

Applications

Security

Specification Summary

Item	Value
Material	Borosilicate
Shape	Round
Diameter	3 mm
Thickness	0.1 mm
Surface Quality	10/5
Coating	anti-reflective (AR)
MOQ	—

Full Specifications

Parameter	Value
Type	plate
Customized Support	OEM, ODM
Warranty	Available
Weight	As request
Name	Optical Windows
Diameter Tolerance	+/-0.01mm
Thickness Tolerance	+/-0.1mm
Surface Figure	lamda/10(PV flat surface can achieve 0.03um per 150mm)

FAQ

What are the available custom sizes?

Custom sizes can range from 3.0 mm to 460.0 mm in diameter, with specific thickness options.

What are the tolerances for diameter and thickness?

Diameter tolerance is +/-0.01 mm, and thickness tolerance is +/-0.1 mm.
