0.3x5 mm CaF2 Plano-convex Lens, AR Coated

Explore our plano-convex CaF2 lens for microscopy and imaging, with customizable sizes and high performance across multiple wavelengths.

Core attributes

Material: CaF2
Shape: Plano-convex
Diameter: 0.3 mm
Focal Length: 5 mm
Coating: anti-reflective (AR), mgf2
Transmission bands: SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

This plano-convex lens made from CaF2 is ideal for applications in microscopy and imaging across multiple wavelength bands, including 0.4-3 μm. Its design allows for effective light focusing or diverging, making it suitable for various optical systems. With a diameter range from 0.3 mm to 300 mm and a focal length of 5.0 mm, this lens can accommodate diverse project requirements, ensuring reliability and performance in critical applications.

Key Features

Wavelength range: 0.4-3 μm for versatile application compatibility.
Diameter options from 0.3 mm to 300 mm for custom fit in various systems.
Focal length of 5.0 mm for precise imaging capabilities.
High clear aperture of 90% for optimal light transmission.
Coatings of AR and MgF2 enhance performance across specified bands.

Available Sizes

Diameter x Focal Length (mm)
150.2 x 5

Applications

Microscopy, Imaging

Specification Summary

Item	Value
Material	CaF2
Shape	Plano-convex
Diameter	0.3 mm
Focal Length	5 mm
Coating	anti-reflective (AR), mgf2
Transmission bands	SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens…
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	0.04
Clear Aperture	90%

FAQ

Can I get custom sizes for this lens?

Yes, the lens is available in a diameter range from 0.3 mm to 300 mm, with variant sizes including 150.2 mm.

What is the minimum order quantity (MOQ)?

The MOQ is not specified, allowing for flexibility in ordering.
