0.1 mm Fused Silica Achromatic Lens, AR Coated

Achromatic double convex lens in fused silica for 200-2500 nm applications. Custom sizes and OEM support available.

Core attributes

Material: Fused Silica
Shape: Achromatic
Diameter: 0.1 mm
Surface Quality: 60/40
Coating: anti-reflective (AR)
Transmission bands: SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

This achromatic double convex lens made from fused silica is designed for applications across a wide wavelength range of 200-2500 nm, including IR imaging and LIDAR. Its coatings enhance transmittance, making it ideal for precision optical systems. With a diameter of 0.1 mm and a surface quality of 60/40, this lens ensures reliable performance in demanding environments. The lens can be customized to fit specific application needs, ensuring optimal integration into various optical setups.

Key Features

Wavelength range: 200-2500 nm for versatile application in IR and LIDAR systems.
Surface quality of 60/40 ensures clarity and minimal distortion for high-performance imaging.
Diameter tolerance of 0.2 mm allows for precise fitting in custom applications.
Center thickness tolerance of ±0.1 mm supports stringent design specifications.
OEM, ODM, and OBM support available for tailored solutions and prototypes.

Specification Summary

Item	Value
Material	Fused Silica
Shape	Achromatic
Diameter	0.1 mm
Surface Quality	60/40
Coating	anti-reflective (AR)
Transmission bands	SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	0.5
Wavelength	200-2500nm
Diameter Tolerance	0.2mm
Center Thickness Tolerance	±0.1mm
Package	safe

FAQ

Can I get custom sizes for this lens?

Yes, the lens can be customized according to your drawing and specific requirements.

What are the tolerances for diameter and thickness?

The diameter tolerance is ±0.2 mm, and the center thickness tolerance is ±0.1 mm.
