1x150 mm Fused Silica Aspheric Lens, AR Coated

Aspheric convex lens in fused silica for imaging, with customizable sizes and high optical clarity across 0.4-1.7 μm.

Core attributes

Material: Fused Silica
Shape: Aspheric
Diameter: 1 mm
Focal Length: 150 mm
Surface Quality: 40/20
Coating: anti-reflective (AR), uncoated
Transmission bands: NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

This aspheric convex lens made from fused silica is designed for imaging applications across a wide spectral range of 0.4 to 1.7 μm. With a focal length of 150 mm and a diameter range from 1.0 mm to 400.0 mm, it offers versatility for various optical systems. The lens features a surface quality of 40/20 and can be customized for specific design wavelengths, ensuring optimal performance in demanding environments. Its lightweight design and high clear aperture make it suitable for precise imaging tasks.

Key Features

Focal length of 150 mm for optimal imaging performance.
Diameter options from 1.0 mm to 400.0 mm for versatile applications.
Surface quality of 40/20 ensures high optical clarity.
Customizable design wavelength for tailored solutions.
Lightweight at 0.2 kg (0.44 lb) for easy integration.

Available Sizes

Diameter x Focal Length (mm)
200.5 x 150

Applications

Imaging

Specification Summary

Item	Value
Material	Fused Silica
Shape	Aspheric
Diameter	1 mm
Focal Length	150 mm
Surface Quality	40/20
Coating	anti-reflective (AR), uncoated
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM
Warranty	3 Years
Weight	0.2kg(0.44lb)
Design Wavelength	546.1nm or as request
Diameter Tolerance	±0.1mm
Centration	<3 arc minutes
Clear Aperture	> 90%
Flatness	L/4

FAQ

What are the available custom sizes?

The lens is available in diameters from 1.0 mm to 400.0 mm, with variant sizes including 200.5 mm.

What is the diameter tolerance?

The diameter tolerance is ±0.1 mm, ensuring precise fit for your applications.
