0.5 mm Fused Silica Ball Lens

Product description

This optical glass ball lens, made from fused silica, is designed for applications requiring precise light focusing and coupling in the wavelength range of 0.7-1.7 μm. With a diameter of 0.5 mm and a surface quality of 60/40, it ensures reliable performance in various optical setups. The lens is ideal for R&D and production environments where consistent quality and precise specifications are critical.

Key Features

Diameter of 0.5 mm ensures compact integration into optical systems.
Surface quality of 60/40 provides effective light transmission and minimal distortion.
Clear transparent color enhances visibility and light coupling.
Diameter tolerance of 0.00/-0.05 mm ensures high precision for critical applications.
Minimum order quantity of 10 pcs supports small-scale prototyping and testing.

Specification Summary

Item	Value
Material	Fused Silica
Shape	Ball
Diameter	0.5 mm
Surface Quality	60/40
Transmission bands	NIR (0.7-1.7 μm)
MOQ	10pcs

Full Specifications

Parameter	Value
Customized Support	OEM
Warranty	3 Years
Diameter Tolerance	0.00/-0.05mm
Moq	10pcs
Key Word	ball lenses
Color	Clear Transparent
Surface Flatness	1/4@633nm
Use	Optical
Structure	Other

FAQ

Can I get custom sizes for the ball lens?

Yes, custom ball lenses in a range of diameters and materials are available upon inquiry.

What is the minimum order quantity?

The minimum order quantity is 10 pieces.
