2 mm Fused Silica Biconvex Lens, AR Coated
Biconvex Fused Silica lens for 400-700 nm to 1.7-3 μm applications. Custom sizes, high surface quality, and OEM support available.
Core attributes
- Material
- Fused Silica
- Shape
- Biconvex
- Diameter
- 2 mm
- Surface Quality
- 1/4
- Coating
- anti-reflective (AR)
- Transmission bands
- SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- Biconvex
- Diameter
- 2 mm
- Surface Quality
- 1/4
- Coating
- anti-reflective (AR)
- Transmission bands
- SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
This biconvex lens made from Fused Silica is optimized for a wide range of wavelengths, including 400-700 nm, 0.7-1.7 μm, and 1.7-3 μm. It is designed to enhance optical performance in applications such as IR imaging, LIDAR, and laser systems. With a surface quality of 1/4 and customizable dimensions ranging from 1.0 mm to 300.0 mm, this lens addresses the need for precise optical components in various high-tech applications.
Key Features
- High surface quality of 1/4 for superior optical performance.
- Customizable dimensions from 1.0 mm to 300.0 mm to fit specific applications.
- Supports OEM, ODM, and OBM for tailored solutions.
- Clear aperture greater than 90% ensures maximum light transmission.
- Thickness tolerance of ±0.1 mm for reliable batch consistency.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Biconvex |
| Diameter | 2 mm |
| Surface Quality | 1/4 |
| Coating | anti-reflective (AR) |
| Transmission bands | SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens… |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Weight | 0.04 |
| Dimension | 1.0mm-200.0 mm |
| Focus Length | 1mm-100000mm |
| Dimension Tolerance | +0.0/-0.1mm |
| Thickness Tolerance | ±0.1mm |
| Centration | <3' |
| Clear Aperture | >90% |
| Bevelling | <0.2x45° |
FAQ
What are the available custom sizes?
Custom sizes range from 1.0 mm to 300.0 mm in diameter.
What is the MOQ for this lens?
Minimum order quantity (MOQ) details are not specified.
