5 mm Fused Silica Biconvex Lens, AR Coated
Explore high-quality biconvex fused silica lenses for IR imaging and LIDAR applications. Custom sizes available.
Core attributes
- Material
- Fused Silica
- Shape
- Biconvex
- Diameter
- 5 mm
- Surface Quality
- 40/20
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), VIS (400-700 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- Biconvex
- Diameter
- 5 mm
- Surface Quality
- 40/20
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), VIS (400-700 nm)
Product description
This biconvex lens made from fused silica is ideal for applications in the 8-14 μm and 400-700 nm wavelength ranges. Its high-quality surface (40/20) and clear aperture (>90%) ensure optimal performance in IR imaging, LIDAR, and laser applications. The lens features anti-reflective coatings to enhance transmittance, making it suitable for demanding optical systems. Sourced from Zhejiang, this lens combines reliability with precision for advanced optical needs.
Key Features
- Material: Fused Silica for high durability and performance.
- Surface Quality: 40/20 ensures minimal distortion and high clarity.
- Diameter: 5.0 mm with a tolerance of 0.05 mm for precise fitting.
- Clear Aperture: >90% maximizes light transmission for enhanced imaging.
- Centration: <5 arc min for accurate alignment in optical systems.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Biconvex |
| Diameter | 5 mm |
| Surface Quality | 40/20 |
| Coating | anti-reflective (AR) |
| Transmission bands | LWIR (8-14 μm), VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens… |
| Customized Support | OEM, ODM, OBM |
| Warranty | 2 Years |
| Weight | 1 |
| Bevelling | 0.2mm*45° |
| Clear Aperture | >90% |
| Color | Clear transparent |
| Diameter Tolerance | 0.05mm |
| Centration | <5 arc min |
FAQ
Can I get custom sizes for this lens?
Custom sizes are available through OEM, ODM, and OBM support.
What is the minimum order quantity (MOQ)?
The minimum order quantity is not specified; please inquire for details.
