1 mm Fused Silica Lens, AR Coated
AR-coated fused silica lens with high transmittance for medical applications. Custom sizes and thickness available.
Core attributes
- Material
- Fused Silica
- Diameter
- 1 mm
- Thickness
- 0.2 mm
- Transmittance
- 90%
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Diameter
- 1 mm
- Thickness
- 0.2 mm
- Transmittance
- 90%
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
This AR-coated fused silica lens is designed for applications in medical devices, enhancing light transmittance and reducing glare. With a transmittance of up to 99.5%, it effectively improves visibility in high-light environments. The lens is available in a wide diameter range from 1.0 mm to 200.0 mm and thicknesses from 0.21 mm to 5.0 mm, making it suitable for various optical applications requiring high clarity and minimal reflection.
Key Features
- High transmittance of 90% to 99.5% enhances visibility in medical applications.
- Custom sizes available from 1.0 mm to 200.0 mm to fit specific design needs.
- Thickness options from 0.21 mm to 5.0 mm for versatile integration.
- AR coating minimizes reflection, improving clarity and contrast.
- Reliable production in a cleanroom environment ensures batch consistency.
Applications
Medical
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Diameter | 1 mm |
| Thickness | 0.2 mm |
| Transmittance | 90% |
| Coating | anti-reflective (AR) |
| Transmission bands | NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Customized Support | OEM, ODM |
| Warranty | 1 year |
| Transmittance | 90% / 95% / 99.5% |
| Wavelength | 400nm-700nm |
| Color | Transparent |
FAQ
Can I get custom sizes?
Yes, custom sizes are available from 1.0 mm to 2000 mm.
What are the thickness options?
Thickness options range from 0.21 mm to 8.0 mm, with customization available.
