1 mm Fused Silica Lens, AR Coated

Explore our AR anti-reflection optical glass lens with 98% transmittance, customizable sizes, and high-quality manufacturing.

Core attributes

Material: Fused Silica
Diameter: 1 mm
Thickness: 0.2 mm
Surface Quality: 60/40
Transmittance: 98%
Coating: anti-reflective (AR)
Transmission bands: NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

This AR anti-reflection optical glass lens is designed to enhance transmittance across a wide range of wavelengths, making it ideal for applications in IR imaging, LIDAR, and laser systems. With a transmittance of over 98%, this lens minimizes light loss, ensuring optimal performance in critical optical applications. Available in custom diameters from 1.0 mm to 200.0 mm and thicknesses from 0.21 mm to 5.0 mm, it meets diverse project requirements while maintaining high surface quality (60/40).

Key Features

Transmittance of 98% ensures minimal light loss for improved optical performance.
Custom diameters (1.0 mm to 200.0 mm) and thicknesses (0.21 mm to 5.0 mm) available for tailored solutions.
AR coating enhances performance across multiple wavelength bands (0.7-1.7 μm, 400-700 nm, <400 nm).
Manufactured under ISO9001:2015 and ISO14001:2015 certifications for reliable quality assurance.
OEM and ODM support available for customized product specifications.

Specification Summary

Item	Value
Material	Fused Silica
Diameter	1 mm
Thickness	0.2 mm
Surface Quality	60/40
Transmittance	98%
Coating	anti-reflective (AR)
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Transmittance	98%; More than 98%
Customized Support	OEM, ODM
Warranty	18 months
Color	Transparent
Wavelength	200-1200nm /Custom

FAQ

Can I get custom sizes for this lens?

Yes, custom diameters from 1.0 mm to 200.0 mm and thicknesses from 0.21 mm to 5.0 mm are available.

What is the minimum order quantity (MOQ)?

The MOQ is not specified, allowing for flexibility in ordering.
