5 mm Fused Silica Meniscus Lens, AR Coated

Explore customizable meniscus lenses in fused silica for thermal imaging and projection, with precise tolerances and multiple coating options.

Core attributes

Material: Fused Silica
Shape: Meniscus
Diameter: 5 mm
Coating: anti-reflective (AR), uncoated, mgf2
Transmission bands: SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

Meniscus lenses made from fused silica are designed for applications in thermal imaging, projection, and general imaging across multiple wavelength bands, including 0.4-3 μm. Their unique shape minimizes spherical aberration, making them ideal for enhancing optical system performance. With diameters ranging from 5.0 mm to 500.0 mm, these lenses can be tailored to fit specific applications, ensuring optimal results in demanding environments.

Key Features

Customizable dimensions available, supporting OEM and ODM requests.
Diameter tolerance of ±0.1 mm ensures precision fitting.
Centration accuracy of <3 arcmin enhances alignment in optical systems.
Clear aperture greater than 95% maximizes light transmission.
Multiple coating options (AR, uncoated, MgF2) for varied wavelength applications.

Applications

Thermal Imaging, Projection, Imaging

Specification Summary

Item	Value
Material	Fused Silica
Shape	Meniscus
Diameter	5 mm
Coating	anti-reflective (AR), uncoated, mgf2
Transmission bands	SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Meniscus Lens
Customized Support	OEM, ODM, As drawings
Warranty	1 months
Weight	0.05
Diameter Tolerance	±0.1 mm
Focal Length Tolerance	±1%
Centration	<3 arcmin
Clear Aperture	>95%
Chamfer	protective chamfer

FAQ

Can I get custom sizes for these lenses?

Yes, lenses can be customized according to your specifications with OEM and ODM support.

What is the diameter tolerance for these lenses?

The diameter tolerance is ±0.1 mm, ensuring a precise fit for your applications.
