1 / 6Optical Filters
48 mm Fused Silica Optical Filter
High-performance 510nm bandpass filter with 94% transmittance for fluorescence microscopy and photonics applications.
Core attributes
- Material
- Fused Silica
- Size
- 48 mm
- Thickness
- Custom
- Surface Quality
- 60/40
- Transmittance
- 94%
- Filter Type
- bandpass
- Cwl
- 510nm
- Fwhm
- 25nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Size
- 48 mm
- Thickness
- Custom
- Surface Quality
- 60/40
- Transmittance
- 94%
- Filter Type
- bandpass
- Cwl
- 510nm
- Fwhm
- 25nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product description
This 510nm bandpass filter is designed for applications requiring high transmittance and effective blocking in the 400-700 nm range. With a transmittance of 94% and a full width at half maximum (FWHM) of 25nm, it ensures optimal performance for fluorescence microscopy and other photonics applications. The filter is made from durable fused silica and features an iad-pvd coating for enhanced environmental durability, making it suitable for various laboratory and industrial settings.
Key Features
- 94% transmittance ensures high light throughput for enhanced imaging quality.
- Bandpass filter type effectively isolates the desired wavelength while blocking unwanted light.
- FWHM of 25nm provides precise wavelength selection for accurate measurements.
- Durable fused silica construction offers excellent thermal and environmental stability.
- Customizable options available, including OEM and ODM support for tailored solutions.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Size | 48 mm |
| Thickness | Custom |
| Surface Quality | 60/40 |
| Transmittance | 94% |
| Filter Type | bandpass |
| Cwl | 510nm |
| Fwhm | 25nm |
| Coating | iad-pvd |
| Transmission bands | VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 94%; T>94% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Coating Region | Single-sided or double-sided |
| Blocking Density | OD>2@300-1050nm |
| Tolerance | ± 0.10mm |
| Certification | ISO9001,RoHs,EPR |
| Shipment | Express delivery,Air,Sea |
FAQ
Can I get custom sizes for this filter?
Yes, customizable options are available, including OEM and ODM support.
What is the tolerance for this filter?
The tolerance for this filter is ± 0.10mm.
