Custom Size Fused Silica Optical Filter
Bandpass filter for fluorescence and microscopy with 85% transmittance at 557 nm. Custom thickness options available.
Core attributes
- Material
- Fused Silica
- Size
- Custom
- Thickness
- 1 mm
- Surface Quality
- 40/20
- Transmittance
- 85%
- Filter Type
- bandpass
- Cwl
- 557nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Size
- Custom
- Thickness
- 1 mm
- Surface Quality
- 40/20
- Transmittance
- 85%
- Filter Type
- bandpass
- Cwl
- 557nm
- Coating
- iad-pvd
- Transmission bands
- VIS (400-700 nm)
Product description
This bandpass filter is specifically designed for applications in fluorescence and microscopy, effectively transmitting light around the center wavelength of 557 nm. With a transmittance of 85%, it ensures optimal light throughput while blocking unwanted wavelengths. The filter is made from high-quality fused silica, providing excellent durability and reliability for various research applications. Its customizable thickness options of 1.0 mm and 5.0 mm cater to specific experimental needs.
Key Features
- Transmittance of 85% for enhanced light efficiency.
- Center wavelength of 557 nm aligns with common fluorescence applications.
- Custom thickness options (1.0 mm, 5.0 mm) for tailored fit.
- Steeper slope for improved wavelength selectivity.
- Surface quality of 40/20 ensures minimal distortion.
Applications
Fluorescence, Microscopy
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Size | Custom |
| Thickness | 1 mm |
| Surface Quality | 40/20 |
| Transmittance | 85% |
| Filter Type | bandpass |
| Cwl | 557nm |
| Coating | iad-pvd |
| Transmission bands | VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 85% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Substrate | B270,D263T,Quartz Glass,Float glass |
| Tolerance | ±0.2 mm |
| Slope | Steeper |
| Aoi | Can be customized |
| Certification | ISO9001,RoHS,EPR |
FAQ
Can I get custom sizes?
Custom thickness options of 1.0 mm and 5.0 mm are available.
What are the tolerances for this filter?
The filter has a tolerance of ±0.2 mm.
