1 / 6Optical Filters
Custom Size Fused Silica Optical Filter, AR Coated
High-performance bandpass filter at 950 nm with 90% transmittance, ideal for near-infrared applications.
Core attributes
- Material
- Fused Silica
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- bandpass
- Cwl
- 950nm
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm)
Product facts
Key attributes
- Material
- Fused Silica
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- bandpass
- Cwl
- 950nm
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm)
Product description
This bandpass filter is designed for applications requiring high transmittance in the near-infrared spectrum, specifically centered at 950 nm with a full width at half maximum (FWHM) of 60 nm. With a transmittance of 90%, it effectively allows desired wavelengths to pass while blocking unwanted light. Ideal for fluorescence microscopy, machine vision, and other life-science applications, this filter ensures reliable performance under various conditions.
Key Features
- High transmittance of 90% ensures optimal light passage for effective imaging.
- Center wavelength at 950 nm tailored for specific near-infrared applications.
- Durable fused silica material provides environmental stability and longevity.
- AR coating enhances performance by reducing reflections.
- Customizable options available for OEM, ODM, and OBM support.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Size | Custom |
| Thickness | Custom |
| Transmittance | 90% |
| Filter Type | bandpass |
| Cwl | 950nm |
| Coating | anti-reflective (AR) |
| Transmission bands | NIR (0.7-1.7 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 90%; T>90% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Color | Clear Transparent |
| Cwl | 950nm |
| Fwhm | 60nm |
FAQ
Can I get custom sizes?
Yes, customizable options are available for OEM, ODM, and OBM support.
What is the minimum order quantity (MOQ)?
The MOQ is not specified, allowing flexibility in ordering.
Product inquiry
Request a quote
Share your application and target specifications. Optional optical details help clarify the request.
