10 mm Fused Silica Optical Window, AR Coated

Product description

This fused silica laser protection window is designed for laser cutting applications, particularly effective in the 0.7-1.7 μm and 400-700 nm bands. It protects focus lenses from debris and spatter, ensuring optimal performance in machines from various leading brands. With a clear aperture greater than 90%, it offers high transmittance and durability, making it suitable for high-power laser systems.

Key Features

Diameter options from 10.0 mm to 200.0 mm for versatile application fit.
Customizable with OEM, ODM, and OBM support to meet specific project needs.
High damage threshold (> 15 J/cm²) ensures longevity under intense laser conditions.
Tolerances of +/-0.02 mm to +/-0.1 mm for precise fitting in various systems.
AR coatings enhance transmittance, improving efficiency in laser operations.

Applications

Laser Cutting

Specification Summary

Item	Value
Material	Fused Silica
Diameter	10 mm
Thickness	Custom
Coating	anti-reflective (AR)
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	plano, Plano Convex Lens, Convex Lens
Customized Support	OEM, ODM, OBM
Warranty	2 years
Weight	as design
Tolerance	+/-0.02mm to +/-0.1mm
Chamfer	as needed
Clear Aperture	>90%

FAQ

What are the available custom sizes?

Diameter options range from 10.0 mm to 200.0 mm, with standard thickness or custom thickness available.

What is the minimum order quantity?

Minimum order quantity details are not specified; please inquire for specific requirements.
