1 / 6Optical Windows
5 mm Fused Silica Optical Window, AR Coated
Explore our Fused Silica Optical Dome Window with customizable sizes and high surface quality for various optical applications.
Core attributes
- Material
- Fused Silica
- Diameter range
- 5–300 mm
- Coating
- ar
Product facts
Key attributes
- Material
- Fused Silica
- Diameter range
- 5–300 mm
- Coating
- ar
Product description
The Optical Dome Window made from Fused Silica is ideal for various optical applications, providing excellent performance across a wide range of wavelengths. With a diameter range of 5 to 300 mm and a surface quality of 1/2, this window ensures high transmittance and minimal distortion. Its AR coating enhances light transmission, making it suitable for demanding environments in IR imaging, LIDAR, and laser applications.
Key Features
- Diameter range: 5 to 300 mm for versatile application fit.
- Surface quality of 1/2 ensures minimal distortion and high clarity.
- AR coating enhances transmittance, improving optical performance.
- Clear aperture of 95% maximizes light throughput.
- Customizable options available through OEM and ODM services.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Diameter | 5 mm |
| Thickness | Custom |
| Surface Quality | 1/2 |
| Coating | anti-reflective (AR) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | dome lens; Optical Dome Window |
| Customized Support | OEM, ODM |
| Warranty | 3years |
| Weight | 0.5kg |
| Clear Aperture | 95% |
| Parallelism | 3arcmin |
| Certification | ISO9001 |
FAQ
What are the available custom sizes?
The Optical Dome Window can be customized in diameter from 5 mm to 300 mm.
What is the tolerance for the diameter?
The diameter tolerance is +/-0.05 mm.
