0.2x200 mm Fused Silica Plano-convex Lens, AR Coated

Discover plano-convex fused silica lenses for medical and microscopy applications, customizable and optimized for UV and visible light.

Core attributes

Material: Fused Silica
Shape: Plano-convex
Diameter: 0.2 mm
Focal Length: 200 mm
Coating: anti-reflective (AR), mgf2
Transmission bands: VIS (400-700 nm), UV (<400 nm)

Product description

The plano-convex lens made from fused silica is ideal for applications in medical imaging and microscopy, particularly in the UV and visible light ranges (400-700 nm). With a focal length of 200 mm and a diameter of 0.2 mm, this lens effectively focuses light, enhancing image clarity and detail. Its anti-reflective and MgF2 coatings improve transmittance, making it suitable for precision optical systems. Custom sizes can be accommodated, ensuring fit for specific applications.

Key Features

Focal length of 200 mm for precise imaging applications.
Diameter of 0.2 mm allows for compact integration in optical systems.
AR and MgF2 coatings enhance light transmission and reduce reflections.
Center thickness of 5.1 ± 0.1 mm for consistent performance.
Clear aperture of 85% of diameter ensures maximum light utilization.

Available Sizes

Diameter x Focal Length (mm)
0.2 x 200

Applications

Medical, Microscopy, Imaging

Specification Summary

Item	Value
Material	Fused Silica
Shape	Plano-convex
Diameter	0.2 mm
Focal Length	200 mm
Coating	anti-reflective (AR), mgf2
Transmission bands	VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Customized Support	OEM, ODM
Center Thickness	5.1+/-0.1 mm
S/D	10/5
Clear Aperture	85% of dia
Certification	ISO9001,ROHS

FAQ

Can I get custom sizes for this lens?

Yes, custom sizes are available upon request, accommodating diameters from 2.0 to 500 mm.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing for flexible procurement.
