1x500 mm Fused Silica Plano-convex Lens, AR Coated

Product description

This plano-convex lens made from fused silica is ideal for imaging applications, providing excellent optical clarity and durability. With a focal length of 500 mm and a diameter range from 1.0 mm to 500.0 mm, it accommodates various setups. The lens features a surface quality of 40/20 and a clear aperture of at least 80% of the diameter, ensuring optimal performance in light convergence. Its anti-reflective coating enhances visibility and contrast, making it suitable for demanding optical systems.

Key Features

Focal length of 500 mm for precise imaging applications.
Surface quality of 40/20 ensures high clarity and minimal distortion.
Tolerances of ±0.05 mm for optimal alignment in optical setups.
Clear aperture of at least 80% for sharp and clear images.
Available in customizable sizes up to 500 mm in diameter.

Available Sizes

Diameter x Focal Length (mm)
250.5 x 500

Applications

Imaging

Specification Summary

Item	Value
Material	Fused Silica
Shape	Plano-convex
Diameter	1 mm
Focal Length	500 mm
Surface Quality	40/20
Coating	anti-reflective (AR)

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	0.05
Tolerance	+/-0.05mm
Surface Flatness	1/4@633nm
Clear Aperture	>=central 80% of diameter

FAQ

What are the available sizes for this lens?

The lens is available in diameters ranging from 1.0 mm to 500.0 mm, with customizable sizes up to 500 mm.

What is the tolerance for this lens?

The lens has a tolerance of ±0.05 mm, ensuring precise alignment in applications.
