1 mm Fused Silica Plano-convex Lens, AR Coated

Fused silica plano-convex lenses for 0.4-3 μm applications. Custom sizes, high quality, and OEM/ODM support available.

Core attributes

Material: Fused Silica
Shape: Plano-convex
Diameter: 1 mm
Surface Quality: 1/4
Coating: anti-reflective (AR)
Transmission bands: SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

Fused silica plano-convex lenses are ideal for applications across multiple spectral bands, including 0.4-3 μm. They provide high transmittance and surface quality of 1/4, making them suitable for IR imaging, LIDAR, and laser applications. With a diameter range from 1.0 mm to 300.0 mm, these lenses can be tailored to fit specific project needs, ensuring optimal performance in various environments.

Key Features

Broad wavelength compatibility (0.4-3 μm) for diverse applications.
High surface quality (1/4) ensures minimal distortion.
Custom diameters from 1.0 mm to 300.0 mm support various designs.
OEM/ODM support for tailored solutions and prototypes.
Lightweight design (0.04 kg) facilitates easy integration.

Specification Summary

Item	Value
Material	Fused Silica
Shape	Plano-convex
Diameter	1 mm
Surface Quality	1/4
Coating	anti-reflective (AR)
Transmission bands	SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens…
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	0.04
Dimension	1.0mm-200.0 mm
Focus Length	1mm-100000mm
Dimension Tolerance	+0.0/-0.1mm
Thickness Tolerance	±0.1mm
Centration	<3'
Clear Aperture	>90%
Bevelling	<0.2x45°

FAQ

What are the available custom sizes?

Lenses can be customized with diameters ranging from 1.0 mm to 300.0 mm.

What are the tolerances for dimensions?

Dimension tolerance is +0.0/-0.1 mm, and thickness tolerance is ±0.1 mm.

Is there a minimum order quantity?

The minimum order quantity is not specified.
