Custom Size Fused Silica Plano-convex Lens, AR Coated
Plano-convex lens made of fused silica for imaging applications, customizable sizes, and high surface quality.
Core attributes
- Material
- Fused Silica
- Shape
- Plano-convex
- Focal Length
- 5 mm
- Surface Quality
- 20/10
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- Plano-convex
- Focal Length
- 5 mm
- Surface Quality
- 20/10
- Coating
- anti-reflective (AR)
Product description
The plano-convex lens made from fused silica is designed for precise optical alignment and imaging applications. With a focal length of 5.0 mm, it provides high-quality imaging with a surface quality of 20/10, ensuring sharp and distortion-free images. The anti-reflective coating enhances light transmission, making it suitable for demanding imaging tasks. This lens is customizable to meet specific requirements, providing flexibility for various applications.
Key Features
- Focal length of 5.0 mm for precise imaging applications.
- Surface quality rated at 20/10 for sharp, distortion-free images.
- Anti-reflective coating reduces glare, enhancing light transmission.
- Customizable sizes available to meet specific project requirements.
- Dimension tolerance of ±0.03 mm ensures batch consistency.
Applications
Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Plano-convex |
| Focal Length | 5 mm |
| Surface Quality | 20/10 |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Aspherical Lens, Convex Lens, Plano Convex Lens |
| Customized Support | OEM, ODM |
| Warranty | 3 months |
| Weight | 0.01 |
| Dimension | 1mm-300mm |
| Dimension Tolerance | ±0.03 |
FAQ
What are the available sizes for customization?
Custom sizes can range from 1 mm to 300 mm in diameter.
What is the surface quality of the lens?
The lens has a surface quality rated at 20/10.
