Custom Size Fused Silica Plano-convex Lens, AR Coated
Explore our plano-convex fused silica lens, ideal for security and medical imaging with >99% transmittance and customizable options.
Core attributes
- Material
- Fused Silica
- Shape
- Plano-convex
- Focal Length
- 7.9 mm
- Surface Quality
- 40/20
- Transmittance
- 99%
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- Plano-convex
- Focal Length
- 7.9 mm
- Surface Quality
- 40/20
- Transmittance
- 99%
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
Product description
This plano-convex lens made from fused silica is ideal for applications in security, medical imaging, and various optical instruments. With a broad transmission range from 0.7 to 14 μm and a high transmittance of over 99%, it effectively meets the demands of infrared imaging and laser applications. Its design ensures optimal performance across multiple wavelengths, making it a versatile choice for R&D and procurement engineers seeking reliable optical components.
Key Features
- High transmittance of >99% ensures minimal loss of light.
- Focal length of 7.9 mm provides precise imaging capabilities.
- Surface quality rated at 40/20 for superior clarity and performance.
- Customizable options available for OEM, ODM, and OBM projects.
- Lightweight design at 0.5 kg (1.10 lb) facilitates easy integration.
Applications
Security, Medical, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Plano-convex |
| Focal Length | 7.9 mm |
| Surface Quality | 40/20 |
| Transmittance | 99% |
| Coating | anti-reflective (AR) |
| Transmission bands | LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Weight | 0.5kg(1.10lb) |
| Wavelength | Coated at 400-700nm |
| Transmittance | T>99% |
| Structure | concave convex |
FAQ
What are the tolerances for diameter and thickness?
Diameter tolerance is +0.00/-0.10 mm for precision and +0.00/-0.02 mm for high precision. Center thickness tolerance is +/-0.10 mm for precision and +/-0.02 mm for high precision.
Is custom sizing available?
Yes, the lens is customizable with support for OEM, ODM, and OBM projects.
