35 mm Fused Silica Rectangle Optical Mirror

Product description

The Rectangular Beam Combiner Mirror is engineered for optimal performance in laser applications, specifically designed to transmit 532 nm green laser light while reflecting the 400-700 nm visible spectrum. Constructed from high-quality fused silica, this mirror ensures stable optical performance, making it ideal for beam combining and optical alignment tasks. With customizable sizes, it meets the diverse needs of R&D and procurement engineers in the laser industry.

Key Features

Transmits 532 nm green laser light for efficient beam combining.
Reflects 400-700 nm visible wavelengths, enhancing optical alignment.
Constructed from fused silica for stable and reliable performance.
Custom sizes available, including 35x25 mm and 70x70 mm.
Supports various laser equipment configurations with tailored specifications.

Applications

Laser

Specification Summary

Item	Value
Material	Fused Silica
Shape	Rectangle
Size	35 mm
Thickness	Custom
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm)

Full Specifications

Parameter	Value
Wavelength	532 nm
Warranty	Unavailable
Product Type	Rectangular Beam Combiner Mirror

FAQ

What custom sizes are available?

Custom sizes include options like 35x25 mm and 70x70 mm, with further customization possible.

What is the minimum order quantity (MOQ)?

The minimum order quantity (MOQ) is not specified, allowing flexibility in procurement.
