5 mm Fused Silica Round Optical Filter
980nm Bandpass Filter for infrared photography with 85% transmittance, hard-coated for durability, suitable for CCD and CMOS cameras.
Core attributes
- Material
- Fused Silica
- Shape
- Round
- Size
- 5 mm
- Thickness
- Custom
- Transmittance
- 85%
- Filter Type
- bandpass
- Cwl
- 980nm
- Coating
- hard-coat
- Transmission bands
- NIR (0.7-1.7 μm)
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- Round
- Size
- 5 mm
- Thickness
- Custom
- Transmittance
- 85%
- Filter Type
- bandpass
- Cwl
- 980nm
- Coating
- hard-coat
- Transmission bands
- NIR (0.7-1.7 μm)
Product description
The 980nm Bandpass Filter is designed for infrared photography applications, particularly suitable for CCD and CMOS cameras. With a center wavelength of 980nm and a transmittance of 85%, this filter effectively isolates the desired infrared light while blocking unwanted wavelengths from 400-1200nm. The hard-coated surface ensures durability and resistance to environmental factors, making it an ideal choice for long-term use in various imaging applications.
Key Features
- 85% transmittance for optimal infrared light capture.
- Hard-coated for enhanced durability and scratch resistance.
- Designed for CCD and CMOS camera compatibility.
- Effective blocking of wavelengths from 400-1200nm (OD>3).
- Customizable options available for OEM, ODM, and OBM.
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Round |
| Size | 5 mm |
| Thickness | Custom |
| Transmittance | 85% |
| Filter Type | bandpass |
| Cwl | 980nm |
| Coating | hard-coat |
| Transmission bands | NIR (0.7-1.7 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | 85% |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Filter Type | 980nm Infrared Photography Filter |
| Coating Type | Hard Coated |
| Scratch-Dig | 40/20,60/40,80/50 |
| Center Wavelength | 980nm |
| Peak Transmission(Tp) | >85% |
| Blocking Band | OD>3,400-1200nm |
| Use | CCD CMOS camera |
FAQ
Can I get custom sizes?
Yes, customizable options are available for OEM, ODM, and OBM.
What is the minimum order quantity?
The minimum order quantity is not specified; please inquire for details.
