3 mm Fused Silica Round Optical Window, AR Coated

Product description

This Fused Silica optical window is designed for applications in the medical field, effectively transmitting light in the 400-700 nm and <400 nm bands. With a diameter range from 3.0 mm to 300.0 mm, it offers versatility for various optical setups. The window features multiple coating options, including anti-reflective (AR) and high-reflective (HR), ensuring optimal performance for specific applications. Its robust construction and customizable features make it an ideal choice for R&D and procurement engineers seeking reliable optical components.

Key Features

Diameter options from 3.0 mm to 300.0 mm for versatile applications.
Surface quality of 80/50 ensures high clarity and minimal distortion.
Coating options include AR and HR for enhanced transmittance.
Parallelism of 3’ or as requested, tailored to specific requirements.
Clear aperture of ≥90% maximizes light transmission efficiency.

Applications

Medical

Specification Summary

Item	Value
Material	Fused Silica
Shape	Round
Diameter	3 mm
Thickness	Custom
Surface Quality	80/50
Coating	anti-reflective (AR), uncoated, high-reflective (HR)
Transmission bands	VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	Optical window; Optical Windows
Customized Support	OEM
Warranty	1 Year
Weight	/
Substrate	Fused Silica/K9/BK7/CaF2/BaF2/MgF2/Sapphire
Parallelism	3’ or as your request
Surface Flatness	L/2 or customized
Bevel	Protective bevel as needed
Clear Aperture	≥90%

FAQ

Can I get custom sizes?

Yes, the optical windows are available in diameters ranging from 3.0 mm to 300.0 mm.

What is the minimum order quantity (MOQ)?

The minimum order quantity (MOQ) is not specified, allowing for flexible procurement.
