1 / 6Optical Windows
Custom Size Fused Silica Round Optical Window, AR Coated
Round convex lens made of fused silica, ideal for medical applications, with customizable sizes and high transmittance.
Core attributes
- Material
- Fused Silica
- Shape
- round
- Thickness
- 1–50 mm
- Coating
- ar
Product facts
Key attributes
- Material
- Fused Silica
- Shape
- round
- Thickness
- 1–50 mm
- Coating
- ar
Product description
This round convex lens, crafted from fused silica, is ideal for medical applications and designed for optimal performance in the 0.7-3 μm wavelength range. With a thickness ranging from 1.0 to 50.0 mm and a clear aperture of over 90%, it ensures high transmittance and precision. The lens features anti-reflective coatings to enhance efficiency, making it suitable for various optical systems. Its customizable options cater to specific project needs, ensuring compatibility with diverse applications.
Key Features
- Wavelength compatibility: 0.7-3 μm for versatile applications.
- Thickness range: 1.0 to 50.0 mm allows for tailored solutions.
- Clear aperture: >90% ensures minimal light loss.
- Diameter tolerance: +0/-0.1 mm for precise fitting.
- Custom support: OEM, ODM, and OBM options available.
Applications
Medical
Specification Summary
| Item | Value |
|---|---|
| Material | Fused Silica |
| Shape | Round |
| Diameter | Custom |
| Thickness | 1 mm |
| Coating | anti-reflective (AR) |
| Transmission bands | SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens |
| Customized Support | OEM, ODM, OBM; OBM OEM ODM |
| Warranty | 3 Years |
| Weight | 0.05kg |
| Diameter Tolerance | +0/-0.1mm |
| Thickness Tolerance | ±0.1mm |
| Clear Aperture | >90% |
FAQ
Can I get custom sizes for this lens?
Yes, custom sizes are available to meet specific project requirements.
What are the thickness tolerances?
The thickness tolerance for this lens is ±0.1 mm.
