Custom Size Germanium Plano-convex Lens, AR Coated
High-performance plano-convex Germanium lens for thermal imaging, featuring 100 mm focal length and >87% transmission.
Core attributes
- Material
- Germanium
- Shape
- Plano-convex
- Focal Length
- 100 mm
- Coating
- anti-reflective (AR), diamond-like carbon (DLC)
- Transmission bands
- LWIR (8-14 μm)
Product facts
Key attributes
- Material
- Germanium
- Shape
- Plano-convex
- Focal Length
- 100 mm
- Coating
- anti-reflective (AR), diamond-like carbon (DLC)
- Transmission bands
- LWIR (8-14 μm)
Product description
This plano-convex lens made from Germanium is designed for applications in thermal imaging and related fields, operating effectively within the 8-14 μm wavelength range. With a focal length of 100 mm and a high average transmission exceeding 87% in the 8-12 μm band, it ensures optimal performance for thermal applications. The lens features a motorized adjustable focus mechanism, making it suitable for precise imaging tasks.
Key Features
- Focal length of 100 mm for versatile imaging applications.
- Average transmission >87% in the 8-12 μm range for enhanced performance.
- Motorized adjustable focus mechanism allows for precise control.
- Operating temperature range of -40°C to +60°C for diverse environments.
- IP67 sealing for protection against dust and water ingress.
Applications
Thermal Imaging, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | Germanium |
| Shape | Plano-convex |
| Focal Length | 100 mm |
| Coating | anti-reflective (AR), diamond-like carbon (DLC) |
| Transmission bands | LWIR (8-14 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Aspherical Lens |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 years |
| Weight | 870g |
| Focus Mechanism | Motorized adjustable |
| Operating Temperature | 40°C ~ +60°C |
| Storage Temperature | 50°C ~ +70°C |
| Use | Optical |
| Structure | Plano-convex |
FAQ
Is custom sizing available?
Custom support is available, including OEM, ODM, and OBM options.
What is the minimum order quantity?
Minimum order quantity details are not specified.
