5 mm Germanium Spherical Lens

Product description

This spherical Germanium lens is designed for thermal imaging and general imaging applications, enhancing accuracy in night vision systems. With a diameter range of 5.0 mm to 200.0 mm and thickness options from 0.1 mm to 100.0 mm, it offers versatility for various optical needs. The lens features a 90% clear aperture for optimal light transmission and precision flatness specifications, making it suitable for demanding imaging tasks.

Key Features

Diameter range: 5.0 mm to 200.0 mm for versatile applications.
Thickness options from 0.1 mm to 100.0 mm accommodate diverse requirements.
90% clear aperture ensures optimal light transmission for high-quality imaging.
Precision flatness of 1/2Lambda to 1/10 Lambda for enhanced imaging accuracy.
Customizable dimensions available through OEM, ODM, and OBM support.

Applications

Thermal Imaging, Imaging

Specification Summary

Item	Value
Material	Germanium
Shape	Spherical
Diameter	5 mm
Thickness	0.1 mm
Surface Quality	20/10

Full Specifications

Parameter	Value
Type	Spherical
Customized Support	OEM, ODM, OBM
Warranty	1year
Weight	custom
Clear Aperture	90%
Chamfer	0.1-0.5*45
Flatness	1/2Lambda~ 1/10 Lambda

FAQ

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified.

Can I get custom sizes for this lens?

Yes, customizable dimensions are available through OEM, ODM, and OBM support.
