Custom Size Glass Aspheric Lens, AR Coated
Aspherical lens for thermal imaging with >84% transmission, IP67 rated, and OEM support for custom solutions.
Core attributes
- Material
- Glass
- Shape
- Aspheric
- Focal Length
- 5.7 mm
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- Glass
- Shape
- Aspheric
- Focal Length
- 5.7 mm
- Coating
- anti-reflective (AR)
Product description
This aspherical lens is designed for applications in thermal imaging, security, and general imaging, providing superior performance in the 8-12 µm wavelength range. With an average transmission exceeding 84%, it ensures high efficiency for critical imaging tasks. The lens features a fixed focus mechanism and is IP67 rated for durability in challenging environments. Its compact design and reliable performance make it ideal for R&D and production in various optical applications.
Key Features
- Average transmission >84% in the 8-12 µm band for enhanced imaging clarity.
- Fixed focus mechanism ensures consistent performance across applications.
- IP67 rating for front lens provides protection against dust and water.
- Operating temperature range of -40°C to +80°C suitable for diverse environments.
- OEM support available for customized solutions to meet specific project needs.
Applications
Thermal Imaging, Security, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | Glass |
| Shape | Aspheric |
| Focal Length | 5.7 mm |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Aspherical Lens |
| Customized Support | OEM |
| Warranty | 1 year |
| Weight | 100g |
| Average Transmission(8~12Μm) | >84% |
| Focus Mechanism | Fixed focus |
| Back Focal Length | 9.87mm |
| Sealing | IP67-Front lens only |
| External Coating | High Efficiency AR |
| Operating Temperature | 40°C ~ +80°C |
| Storage Temperature | 50°C ~ +80°C |
| Mechanical Interface | M34 x 0.5 |
FAQ
Is custom sizing available?
Custom sizing options are available through OEM support.
What is the minimum order quantity (MOQ)?
The minimum order quantity is not specified; please contact for details.
Product inquiry
Request a quote
Share your application and target specifications. Optional optical details help clarify the request.
