Custom Size Glass Optical Mirror, AR Coated

Product description

This glass reflective mirror is designed for laser applications, providing high performance across the spectral bands of 0.7-1.7 μm and 400-700 nm. With a surface quality of 60/40 and a flatness of 1/4 Lambda, it ensures minimal wavefront distortion, making it ideal for precision optical setups. The dielectric HR and AR coatings enhance reflectance while maintaining durability, catering to demanding environments.

Key Features

High-performance dielectric HR coating for superior reflectance in specified bands.
Surface quality of 60/40 ensures minimal distortion for laser applications.
Flatness of 1/4 Lambda supports high wavefront quality.
Clear aperture of 98% maximizes light transmission.
Lightweight design at 0.5 kg for easy integration.

Applications

Laser

Specification Summary

Item	Value
Material	Glass
Size	Custom
Thickness	Custom
Surface Quality	60/40
Coating	anti-reflective (AR), dielectric HR
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm)

Full Specifications

Parameter	Value
Type	Reflective Mirror; Prism
Weight	0.5
Color	Clear Transparent
Flatness	1/4 Lambda
Clear Aperture	98%

FAQ

Can custom sizes be ordered?

Custom sizes are not specified, but inquire for potential options.

What is the minimum order quantity?

Minimum order quantity (MOQ) details are not provided; please contact for specifics.
