10 mm K9 Cube Beamsplitter

Product description

This K9 cube beamsplitter is designed for projection applications, offering a reliable 60/40 split ratio. Its high surface quality of 60/40 ensures minimal distortion, making it suitable for high-precision optical setups. With a clear aperture greater than 90%, it maximizes light transmission while maintaining image integrity. The right-angle design facilitates easy integration into various optical systems.

Key Features

60/40 split ratio for balanced light division, enhancing projection clarity.
Surface quality rated at 60/40, ensuring minimal optical distortion.
Clear aperture greater than 90% for optimal light transmission.
Customizable dimensions from 5-50mm to fit specific application needs.
Angle tolerance of 90°± 3 arcminute for precise alignment.

Applications

Projection

Specification Summary

Item	Value
Material	K9
Shape	Cube
Size	10 mm
Thickness	Custom
Surface Quality	60/40
Split Ratio	60/40

Full Specifications

Parameter	Value
Prism Type	Right Angle Prism
Customized Support	OBM, ODM, OEM
Warranty	3 Years
Dimension	5-50mm Or Customized
Dimension Tolerance	+0.0/- 0.1mm
Angle Tolerance	90°± 3 arcminute
Surface Flatness	1/4Lambda@632nm
Clear Aperture	>90%

FAQ

What are the available custom sizes?

Custom sizes range from 5mm to 50mm, allowing for tailored solutions.

What is the dimension tolerance?

The dimension tolerance is +0.0/-0.1mm, ensuring precise fitting.
