80 mm K9 Optical Filter, AR Coated

Product description

The K9 shortpass filter is designed to effectively block wavelengths above 305 nm while allowing shorter wavelengths to pass through with high transmittance. With a central wavelength of 305 nm and a transmittance of 90%, it is ideal for applications requiring precise light filtering in fluorescence microscopy and other optical systems. The filter’s surface quality of 40/20 ensures minimal distortion, making it suitable for high-resolution imaging applications.

Key Features

Transmittance of 90% ensures high light throughput for optimal performance.
Shortpass filter type effectively blocks unwanted longer wavelengths, enhancing image clarity.
Surface quality of 40/20 minimizes distortion, maintaining image integrity.
Customizable options available for OEM, ODM, and OBM support.
Clear transparent color with a clear aperture of 80%~95% for efficient light passage.

Specification Summary

Item	Value
Material	K9
Size	80 mm
Thickness	Custom
Surface Quality	40/20
Transmittance	90%
Filter Type	shortpass
Cwl	305nm
Coating	anti-reflective (AR)
Transmission bands	UV (<400 nm)

Full Specifications

Parameter	Value
Transmittance	90%; 85%~95%
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Color	Clear Transparent
Clear Aperture	80%~95%
Radius Tolerance	+/-0.5%
Centration	<3 Arcmin

FAQ

Can I get custom sizes for this filter?

Yes, customizable options are available for OEM, ODM, and OBM support.

What is the radius tolerance for this filter?

The radius tolerance is +/-0.5%, ensuring precise fitting in optical systems.
