140 mm K9 Right-angle Optical Prism

Product description

The Right Angle Prism is designed for surveying applications, providing precise beam deviation and reliable optical performance. Crafted from K9 glass, it features a surface quality of 40/20 and a flatness of 1/4 Lambda, ensuring minimal wavefront distortion. This prism’s geometry is ideal for redirecting light paths in various surveying instruments, enhancing measurement accuracy and efficiency.

Key Features

Right-angle geometry for effective light redirection, ensuring accurate measurements in surveying applications.
Surface quality of 40/20 guarantees minimal distortion, maintaining wavefront integrity.
Flatness of 1/4 Lambda supports high precision in optical paths.
OEM customization available for tailored solutions to fit specific project needs.
Origin from Fujian, ensuring reliable manufacturing standards.

Applications

Surveying

Specification Summary

Item	Value
Material	K9
Shape	Right-angle
Size	140 mm
Thickness	Custom
Surface Quality	40/20

Full Specifications

Parameter	Value
Prism Type	Right Angle Prism, Surveyor’S Prisms
Customized Support	OEM
Warranty	None
Flatness	1/4 Lambda
Color	Red

FAQ

Is custom sizing available?

OEM customization is available for tailored solutions to meet specific project requirements.

What is the surface quality of the prism?

The prism has a surface quality of 40/20, ensuring minimal distortion in optical applications.
