5x0.5 mm K9 Round Optical Filter

Product description

This longpass filter is designed for applications requiring effective light transmission beyond 600 nm, making it ideal for fluorescence microscopy and other optical applications. With a center wavelength of 600 nm and a broad spectral range of 400-700 nm, it ensures optimal performance in various light environments. The K9 glass substrate provides durability and reliability in demanding conditions, while customizable sizes accommodate specific project needs.

Key Features

Center wavelength of 600 nm for targeted light filtering, enhancing application specificity.
Broad spectral range of 400-700 nm, suitable for diverse optical applications.
Customizable sizes from 5 mm to 100 mm, allowing for tailored solutions.
Standard bevel and chamfer for easy integration into existing setups.
Clear aperture of ≥90% ensures minimal light loss during transmission.

Available Sizes

Size x Thickness (mm)
52.5 x 2.8

Specification Summary

Item	Value
Material	K9
Shape	Round
Size	5 mm
Thickness	0.5 mm
Surface Quality	80/50
Filter Type	longpass
Cwl	600nm
Transmission bands	VIS (400-700 nm)

Full Specifications

Parameter	Value
Transmittance	/
Customized Support	OEM
Warranty	1 month
Substrate	HB600 or other Color Glass
Structure	Plano-plano
Dimension	5-100mm
Color	Red
Bevel And Chamfer	Standard bevel and chamfer
Clear Aperture	≥90%
Transmission(%)	Send us an inquiry to get T curve

FAQ

Can I get custom sizes?

Yes, sizes can be customized from 5 mm to 100 mm.

What is the minimum order quantity?

Minimum order quantity details are not specified; please inquire for more information.
