1 mm MgF2 Optical Window, AR Coated
MgF2 optical window with >90% transmittance, customizable sizes, ideal for IR imaging and LIDAR applications.
Core attributes
- Material
- MgF2
- Diameter range
- 1–500 mm
- Coating
- ar
Product facts
Key attributes
- Material
- MgF2
- Diameter range
- 1–500 mm
- Coating
- ar
Product description
This optical window, made from MgF2, is ideal for applications across a broad spectral range including 1.7-3 μm, 3-5 μm, and 8-14 μm. With a high transmittance of over 90% and customizable dimensions, it meets the rigorous demands of IR imaging, LIDAR, and medical devices. The window’s flatness of 1/4 Lambda @632.8nm ensures precision in optical performance, making it suitable for critical applications where clarity and accuracy are paramount.
Key Features
- High transmittance of >90% from 193 nm to 6 μm enhances optical performance.
- Customizable diameter from 1.0 mm to 500.0 mm meets specific application needs.
- Flatness specification of 1/4 Lambda @632.8nm ensures superior optical clarity.
- Diameter tolerance of +/-0.05 mm supports precision engineering requirements.
- OEM support available for tailored solutions and prototypes.
Specification Summary
| Item | Value |
|---|---|
| Material | MgF2 |
| Diameter | 1 mm |
| Thickness | Custom |
| Transmittance | 90% |
| Coating | anti-reflective (AR) |
| Transmission bands | LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), VIS (400-700 nm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Customized Support | OEM |
| Warranty | 6 months |
| Weight | customized |
| Diameter Tolerance | +/-0.05mm |
| Flatness | 1/4 Lambda @632.8nm |
| Transmittance | >90% at 193 nm to 6 μm |
| Use | Optical |
| Structure | window |
FAQ
What is the minimum order quantity (MOQ)?
The minimum order quantity (MOQ) is not specified.
Can I get custom sizes?
Yes, the window is customizable in diameter and shape.
