0.7 mm N-BK7 Achromatic Lens, AR Coated

Product description

This achromatic doublet lens is designed for a wide range of applications, including IR imaging, LIDAR, and medical devices, operating across multiple bands from 1.7 to 14 μm. With a diameter range from 0.65 mm to 200 mm, this lens ensures high transmittance and minimal distortion, making it ideal for precise optical systems. The lens is customizable in size and weight, with tight tolerances for diameter and thickness, ensuring reliable performance in demanding environments.

Key Features

Achromatic design minimizes chromatic aberration for enhanced image clarity.
Diameter range of 0.65 mm to 200 mm accommodates various applications.
Diameter tolerance of +/-0.03 mm ensures precision fitting in optical assemblies.
Flatness of 1/4 Lambda @632.8nm guarantees high-quality optical performance.
Customizable support for OEM projects allows for tailored solutions.

Specification Summary

Item	Value
Material	N-BK7
Shape	Achromatic
Diameter	0.7 mm
Coating	anti-reflective (AR), mgf2
Transmission bands	LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), VIS (400-700 nm)

Full Specifications

Parameter	Value
Type	customized
Customized Support	OEM
Warranty	6 months
Weight	customized
Diameter Tolerance	+/-0.03mm
Thickness Tolerance	+/-0.02mm
Clear Aperture	80%~95%
Flatness	1/4 Lambda @632.8nm

FAQ

What is the minimum order quantity (MOQ) for this lens?

The minimum order quantity is not specified, allowing for flexible purchasing options.

Can I get a custom size for this lens?

Yes, the lens is customizable in diameter and weight to fit specific project requirements.
