15x46.7 mm N-BK7 Aspheric Lens, AR Coated

Product description

The aspheric lens made from N-BK7 is designed for effective collimation across a broad wavelength range of 0.7-1.7 μm, 400-700 nm, and <400 nm. With a focal length of 46.67 mm and a diameter of 15 mm, it is ideal for applications in laser systems, ensuring precise light focusing and coupling. This lens can be customized for specific needs, making it suitable for various R&D and industrial applications.

Key Features

Aspheric design enhances light collimation efficiency, improving system performance.
Available in multiple sizes (12.0 mm to 17.0 mm diameter) for versatile application fit.
Compatible with various coatings, including antireflection options for optimized transmittance.
Lightweight at 0.1 kg for easy integration into existing systems.
Custom lens molds available upon request for tailored solutions.

Available Sizes

Diameter x Focal Length (mm)
12 x 40
15 x 46.7
17 x 60

Applications

Collimation

Specification Summary

Item	Value
Material	N-BK7
Shape	Aspheric
Diameter	15 mm
Focal Length	46.7 mm
Coating	anti-reflective (AR), uncoated
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Type	Aspherical Lens
Customized Support	ODM, OBM
Warranty	no
Weight	0.1
Center Thickness	4.2mm

FAQ

Can I get custom sizes for this lens?

Yes, the lens is available in variant sizes ranging from 12.0 mm to 17.0 mm in diameter.

What is the minimum order quantity (MOQ) for this lens?

The MOQ is not specified; however, custom coatings require a minimum purchase volume of 1000 for customization.
